Rated voltage: 230V ~ (1P), 400V~ (2P, 3P, 4P);

Frequency: 50/60Hz

Thermal magnetic release: B curve (3-5In), C curve (5-10In), D curve(10-14In), OV curve (14-20In, the OV curve is only available in 3P 80A);

Number of poles: 1P, 2P, 3P, 4P;

Mechanical life: 20000 cycles;

Electrical life: 6000 cycles (In≤100A); 4000 cycles (In ＞ 100A);

Rated short-circuit breaking capacity(Icn): 10kA;

Short-circuit breaking capacity(Ics): 7.5kA;

Rated impulse withstand voltage(Uimp): 4kV
