| Rated current: | three way(30A) | Rated voltage: | 1000VDC |
| Test voltage: | 6000V(50Hz，1min) | Overvoltage type/pollution index: | CATIII/2 |
| Contact resistance: | three way(1mΩ) | Connector conductor material: | Copper, silver plating |
| Connector insulation material: | PPO | Protection level: | IP2*IP67 |
| Flame retardant grade: | UL94-VO | Safe type: | II |
| Adaptive wire diameter: | 2.5-6.0mm² | Insertion force: | ≤50N |
| Working temperature range | -40°C~+110°C | Pull out force: | ≥50N |
